4D Printing of Complex, Polymeric Structures

by | Dec 22, 2016

Novel 4D printing produces a Sydney Opera House-like 3D structure.

A 4D printing process to produce complex 3D structures via printing of 2D polymer films with induced stresses and subsequent stress release is achieved.

Traditional processing techniques such as molding limit the complexity that can be achieved in resulting constructs, due to the high cost of creating complex molds and the difficulty associated with demolding.

While 3D printing overcomes issues related to demolding and provides a flexible production option for the creation of complex shapes, it has its own limitations. Specifically, the low speed of production that arises because of the layer-by-layer nature of 3D printing. A 4D printing process to overcome both the layer-by-layer bottleneck of 3D printing, and the high cost and the difficulty associated with other traditional techniques has been proposed recently.

Other recent 4D printing techniques have their own limitations specific to the manipulation of the stress required in the production of an object; however, this new process from Xie et al. provides an ultrafast means via visible light polymerization of commercial monomers to specifically define stresses in a 2D polymer film, which can then form a 3D shape via application of heat to release those stresses.

The new technique enabled the production of a 3D theatre (below, d), which reminiscent of the Sydney Opera House, and other complex structures such as a 3D cartoon face.

Demonstration of printing versatility. All the insets represent the planar printing layouts with lighter blue denoting shorter light exposure and white representing no light exposure. All scale bars are 1 cm. a) Printed multi-scale buckled structures. b) 3D cartoon face mask viewed from two different angles. c) Finite element analysis (FEA) modeling of a 3D theater. From left to right: planar printing layout, 3D theater viewed from two different angles, and the corresponding strain map scale. d) Photographic images of actual printed 3D theater viewed from two different angles. e) Printed 4D object, that is, 3D object with active shape changing capability.

Sydney Opera House image from https://pixabay.com/en/sydney-opera-house-australia-363244/ CC0 licence.
